Iron Roughneck

Top Drive Iron Roughneck List

Our Recertified IR3080 Iron Roughneck and ST80 Iron Roughneck both are compact, lightweight, and ready to mount on the rig floor. The Recertified Iron roughnecks simplify the process of making tubular connections on a drill floor by minimizing hazards and streamlining efficiency.

 IR3080 Iron Roughneck and ST80 Iron Roughneck both give you maximize the efficiency of pipe handling operations. IR3080 Iron Roughneck and ST80 Iron Roughneck both ensure the safety and a handy alternative way to the conventional pipe connecting techniques to break out and makeup operations.

IR3080 Iron Roughnecks with 55” Equipment & Arm Assembly

IR3080 Iron Roughnecks with 88” Equipment & Arm Assembly

DESCRIPTION MEASUREMENT DESCRIPTION MEASUREMENT
Weight
7,600lbs (3,447 kg)
Weight
10,000 (4,536 kg)
Spinner Drill Pipe/Collar Capacity
3.5″ – 8.5″
Spinner Drill Pipe/Collar Capacity
3.5″ – 8.5″
Spin Speed (5″ pipe dia.)
80 RPM
Spin Speed (5″ pipe dia.)
80 RPM
Spin Torque
2,250 ft. / lbs. (3,050 N-m)
Spin Torque
2,250 ft / lbs (3,050 N-m)
Wrench Drill Pipe/Collar Capacity
3.5" - 8.5"
Wrench Drill Pipe/Collar Capacity
3.5" - 8.5"
Makeup Torque (maximum)
60,000 ft /lbs (81,349 N-m)
Makeup Torque (maximum)
60,000 ft /lbs (81,349 N-m)
Breakout Torque (maximum)
80,000 ft / lbs (108,465 N-m)
Breakout Torque (maximum)
80,000 ft / lbs (108,465 N-m)
Connection Height (maximum)
68" (172.72 cm) maximum
Connection Height (maximum)
73.5" (186.8cm) maximum
Connection Height (minimum)
30" (76.2 cm) minimum
Connection Height (minimum)
35.5" (90.2cm) minimum
Horizontal Travel
55.5" (141 cm)
Horizontal Travel
88.4" (224.6cm)
Vertical Travel
38" (96.5 cm)
Vertical Travel
38" (96.5 cm)

UTILITY

MEASUREMENT

UTILITY

MEASUREMENT

Hydraulic System Pressure
3000 psi (206.8 bar)
Hydraulic System Pressure
3000 psi (206.8 bar)
Hydraulic System Flow rate
40 gpm (151 Ipm)
Hydraulic System Flow rate
40 gpm (151 Ipm)
Electrical Control Requirements
24VDC (w/customer supplied HPU)
Electrical Control Requirements
24VDC (w/customer supplied HPU)

ST80 Iron Roughnecks Equipment & Arm Assembly

ST80C Iron Roughnecks Equipment & Arm Assembly

DESCRIPTION MEASUREMENT DESCRIPTION MEASUREMENT
Weight
ST-80 Assembly 6,800 lbs. (3,091 kg)
Weight
ST-80C Assembly 7,400 lbs lbs.
Spinner Drill Pipe/Collar Capacity
4 1/4” to 8 1/2”
Spinner Drill Pipe/Collar Capacity
4 1/4” to 8 1/2”
Spin Speed (5″ pipe dia.)
90 RPM
Spin Speed (5″ pipe dia.)
100 RPM
Spin Torque
1,750 ft-lbs (2,373 Nm)
Spin Torque
1,750 ft-lbs (2,373 Nm)
Makeup Torque (maximum)
60,000 ft-lbs (81,500 Nm)
Makeup Torque (maximum)
60,000 ft-lbs (81,500 Nm)
Breakout Torque (maximum)
80,000 ft-lbs (108,500 Nm)
Breakout Torque (maximum)
80,000 ft-lbs (108,500 Nm)
Connection Height
32″ to 68″ (812 mm – 1,727 mm)
Connection Height
32″ to 68″ (812 mm – 1,727 mm)
Horizontal Travel
46″ (1,170 mm)
Horizontal Travel
46″ (1,170 mm)
Vertical Travel
35″ (889 mm)
Vertical Travel
35″ (889 mm)

UTILITY

MEASUREMENT

UTILITY

MEASUREMENT

Hydraulic System Pressure
28 Gpm @ 2,100 Psi 145 bar Min
Hydraulic System Pressure
2,500 psi (172 bar)
Hydraulic System Flow rate
40 GPM (151 L/pm)
Hydraulic System Flow rate
28 gpm @ 1000 psi
Electrical Control Requirements
24VDC (w/customer supplied HPU)
Electrical Control Requirements
24VDC (w/customer supplied HPU)

IR3080 Iron Roughnecks with 55” Arm Assembly

DESCRIPTION MEASUREMENT
Weight
7,600lbs (3,447 kg)
Spinner Drill Pipe/Collar Capacity
3.5″ – 8.5″
Spin Speed (5″ pipe dia.)
80 RPM
Spin Torque
2,250 ft. / lbs. (3,050 N-m)
Wrench Drill Pipe/Collar Capacity
3.5" - 8.5"
Makeup Torque (maximum)
60,000 ft /lbs (81,349 N-m)
Breakout Torque (maximum)
80,000 ft / lbs (108,465 N-m)
Connection Height (maximum)
68" (172.72 cm) maximum
Connection Height (minimum)
30" (76.2 cm) minimum
Horizontal Travel
55.5" (141 cm)
Vertical Travel
38" (96.5 cm)

UTILITY

MEASURMENT

Hydraulic System Pressure
3000 psi (206.8 bar)
Hydraulic System Flow rate
40 gpm (151 Ipm)
Electrical Control Requirements
24VDC (w/customer supplied HPU)

IR3080 Iron Roughnecks with 88” Arm Assembly

DESCRIPTION MEASUREMENT
Weight
10,000 (4,536 kg)
Spinner Drill Pipe/Collar Capacity
3.5″ – 8.5″
Spin Speed (5″ pipe dia.)
80 RPM
Spin Torque
2,250 ft / lbs (3,050 N-m)
Wrench Drill Pipe/Collar Capacity
3.5" - 8.5"
Makeup Torque (maximum)
60,000 ft /lbs (81,349 N-m)
Breakout Torque (maximum)
80,000 ft / lbs (108,465 N-m)
Connection Height (maximum)
73.5" (186.8cm) maximum
Connection Height (minimum)
35.5" (90.2cm) minimum
Horizontal Travel
88.4" (224.6cm)
Vertical Travel
38" (96.5 cm)

UTILITY

MEASUREMENT

Hydraulic System Pressure
3000 psi (206.8 bar)
Hydraulic System Flow rate
40 gpm (151 Ipm)
Electrical Control Requirements
24VDC (w/customer supplied HPU)

ST80 Iron Roughnecks Equipment & Arm Assembly

DESCRIPTION MEASUREMENT
Weight
10,000 (4,536 kg)
Spinner Drill Pipe/Collar Capacity
3.5″ – 8.5″
Spin Speed (5″ pipe dia.)
80 RPM
Spin Torque
2,250 ft / lbs (3,050 N-m)
Wrench Drill Pipe/Collar Capacity
3.5" - 8.5"
Makeup Torque (maximum)
60,000 ft /lbs (81,349 N-m)
Breakout Torque (maximum)
80,000 ft / lbs (108,465 N-m)
Connection Height (maximum)
73.5" (186.8cm) maximum
Connection Height (minimum)
35.5" (90.2cm) minimum
Horizontal Travel
88.4" (224.6cm)
Vertical Travel
38" (96.5 cm)

UTILITY

MEASUREMENT

Hydraulic System Pressure
3000 psi (206.8 bar)
Hydraulic System Flow rate
40 gpm (151 Ipm)
Electrical Control Requirements
24VDC (w/customer supplied HPU)

ST80C Iron Roughnecks Equipment & Arm Assembly

DESCRIPTION MEASUREMENT
Weight
ST-80C Assembly 7,400 lbs lbs.
Spinner Drill Pipe/Collar Capacity
3.5″ – 8.5″
Spin Speed (5″ pipe dia.)
80 RPM
Spin Torque
2,250 ft / lbs (3,050 N-m)
Wrench Drill Pipe/Collar Capacity
3.5" - 8.5"
Makeup Torque (maximum)
60,000 ft /lbs (81,349 N-m)
Breakout Torque (maximum)
80,000 ft / lbs (108,465 N-m)
Connection Height (maximum)
73.5" (186.8cm) maximum
Connection Height (minimum)
35.5" (90.2cm) minimum
Horizontal Travel
88.4" (224.6cm)
Vertical Travel
38" (96.5 cm)

UTILITY

MEASUREMENT

Hydraulic System Pressure
3000 psi (206.8 bar)
Hydraulic System Flow rate
40 gpm (151 Ipm)
Electrical Control Requirements
24VDC (w/customer supplied HPU)

Key Features

Compact size and lightweight: These features of IR3080 and ST80 drills make them ideal for small drill floors. These Iron Roughneck also can relocate away from personnel when fully retracted, providing clearance underneath.

Intuitive control methods: Via a local control panel on the tool, hard-wired remote control, or wireless remote. Advanced remotes can be used for increased automation and safety by automatically performing complete make/break cycles in the driller’s cabin.

Soft clamp: Soft clamp minimizes the amount of force applied to a connection during spinning operations. This helps eliminate “belling” when making thin-walled connections, extending tool joint life, and quickening makeup/breakout times.

Tool shutdowns: Tool shutdowns are the primary way to disable any iron roughneck functions with an easily accessible button or sensor, enabling complete control for a user.

Hydraulic and electrical interlocks: These interlocks systems can be used as additional safety features for the user. Enable/disable certain functions on your machine to keep you safe from potential accidents or mistakes while working with them.

Proximity and analog position sensors: This feature identifies the tool’s position in connecting to the tubular.

Benefits

  • The IR 3080 and ST 80 Iron Roughneck ensures enhanced safety for drill floor tasks, tongs, catheads reduced, and pipe spinners by mechanizing or automating the process.
  • IR 3080 and ST 80 produce the efficiency for routine break or make operations with real-time safety.
  • Easy and effective control panels for quick responsiveness and easy in tool operation.
  • Easily configurable and established Iron Roughneck spare parts sets for streamlined maintenance.
  • IR 3080 and ST 80 Roughneck Provides impact resistance, structural stability, and durability.
  • Ensure the longer lifeline with the lower cost of ownership
  • Balance and upgradable torque provide the maximum cost per square foot of rig floor space.
  • Effective and Simplified lubrication process

Field Support & Engineering

Our field service technicians are ready to help you if your equipment is experiencing any type of issue. We can also provide assistance with electrical problems and software troubleshooting quickly and efficiently onsite so that everything gets taken care of immediately!

Our field engineering group has a deep understanding of what it takes, and field engineering groups have a unique service of providing one-off, rig-specific equipment designs, and modifications.

Our dedicated Field support team is ready to assets you 24/7. For 24/7 Field Support, Call 1-866-664-7373



Repair & Rebuild

Our expertise top drive technicians are ready to solve all your repairing, rebuilding and recertifying process. At Canadian Global, we provide quality assurance with our vast network of repair centers. We ensure quality customer service, unmatched technical integrity, and on-time delivery. Our rebuild iron roughnecks and repair iron roughnecks process system is highly professional to serve you well.



Technical Support

Our expert technical team will be dedicated to all kinds of technical support, troubleshooting, and equipment needs at one phone call. Our highly skilled and experienced technical support team works with our global pool of qualified field service technicians to keep your rigs running.
